FlexMax-2
FLMX-2-FH-P
Production information
Our products enable to use nearly all wasted transport space. Doubling palletized loads through exploiting unused space in nearly all means of transport Maximizing usage of floor space in any transport vehicle, but particularly in reefers, containers and flatbeds. It can effectively increase the transportation volume, especially for goods that cannot be stacked, save the transportation cost and improve safety protection.
Our advantage：
- Considerable reduced CO₂ emission
- Fewer truck
- Safe for fragile products
- Fully certified
- Worldwide patent
Considerable reduced CO₂ emission
Fewer truck
Safe for fragile products
Fully certified
Worldwide patent
Specification：
| 1 | Dynamic stack load (WLL) | Weight Load Limit | 600kg |
| 2 | Dimensions (single) frame | Width | 1218mm |
| Depth | 235mm | ||
| Height | 1335mm | ||
| Height from ground to bottom of 2nd pallet | 1285mm | ||
| Material thickness | 4-8mm | ||
| 3 | Weight frame | incl. Retractable Ratchet straps (4x) | 34kg |
| 4 | Material | Special aluminum alloy | |
| 5 | Features | Temperature range | -50℃ ~ 80 |
| Material (frame) lifetime | 15 years | ||
Pallet size:1000*1200mm
Pallet size:800*1200mm
4 ways forklift entry
Fast & simple handling
STEPS：
